-Put the hood on the sparking plug as far as it will

go;

- Refit the central flap.

CAUTION

THE SPARK PLUG MUST BE REMOVED WHEN THE MO-

TOR IS COLD. THE SPARK PLUG MUST BE REPLACED

EVERY 5000 KM. USE OF STARTERS NOT CONFORMING

OR SPARK PLUGS NOT THOSE DESCRIBED CAN SERI-

OUSLY DAMAGE THE ENGINE.

Characteristic

Recommended spark plug

CHAMPION RN3C

Electric characteristic

Electrode gap

0.6 to 0.7 mm.

Locking torques (N*m)

Spark plug 25 - 30 Nm

Hub oil

Check

A new hub oil dipstick (item no. 832019) has been

introduced. This dipstick differs from the previous

one in that it is 5 mm longer and has a cube on the

lower end with a dot at the centre of two of its four

side faces. Such dot is the reference for the engine

oil level check on the Beverly; (see figure).

Do the following to check the correct level:

1) Stand the vehicle on the centre-stand on flat

ground;

2) Remove the dipstick «A», and dry it with a clean

cloth. Reinsert it, screwing it in all the way;

3) Remove the stick and check that the oil level is

slightly over the second notch starting from the

lower end;

4) Screw the dipstick back in, checking that it is

locked in place.
