Transmission
TRANSMISSION
Specification Desc./Quantity
Transmission With automatic expandable pulley variator, torque server, V-
belt, automatic clutch, gear reduction unit.
Capacities
CAPACITY
Specification Desc./Quantity
Rear hub oil Quantity : ~ 85 cc
Mixer oil 1.2 litres
Fuel tank capacity 6 litres (of which 1 l is reserve)
Electrical system
ELECTRICAL SYSTEM
Specification Desc./Quantity
Ignition type Capacitive discharge electronic ignition, with incorporated HV
coil
Ignition advance (before TDC) Fixed 17° ± 1
Recommended spark plug CHAMPION RN3C
Battery 12V-4Ah
Main fuse 7.5 A
Generator In alternate current with three output sections
Frame and suspensions
FRAME AND SUSPENSION
Specification
Desc./Quantity
Type of chassis Welded tubular steel chassis with stamped sheet reinforce-
ments.
Front suspension mechanical telescopic steering tube
Front suspension stroke 66,8 mm
Trail 100 mm
Rear suspension Single hydraulic double-acting shock absorber, helical coaxial
spring. Chassis to engine support with swinging arm.
Rear suspension bump position 70 mm
Brakes
BRAKE
Specification
Desc./Quantity
Front brake Ø 220 mm disc brake with hydraulic linkage (r.h. brake lever).
Rear brake drum brake (Ø 140 mm) with mechanical linkage.(l.h. brake
lever).
Liberty 50 Catalyzed Characteristics
CHAR - 9
