VEHICLE TECHNICAL DATA
Chassis Tubular and sheet steel
Front suspension The roll system is composed of an
articulated parallelogram
suspension with die-cast
aluminium control arms and two
side headstocks plus shock
absorbers with hydraulic locking
system.
Rear suspension Two double-acting shock
absorbers, adjustable to four
positions at preloading.
Front brake Ø 240-mm double disc brake with
hydraulic control operated by the
handlebar right-hand lever.
Rear brake Ø 240-mm disc brake with
hydraulic control operated by the
handlebar left-hand lever.
Wheel rim type Light alloy wheel rims.
Front wheel rim 13" x 3.00"
Rear wheel rim 14" x 3.75"
Front tyre Without inner tube 110/70 13" 48P
Rear tyre Without inner tube: 140/60-14" 64P
Front tyre pressure 1.7 bar
Rear tyre pressure 2.2 bar (2.6 bar with passenger)
Kerb weight 212 kg (200 kg for version NRL
without front suspension block and
parking brake locking)
84
