PIAGGIO X7 EVO 300ie User Manual

02_04
02_05
Shock absorbers adjustment (02_04, 02_05)
The preloading of the springs can be adjusted to 4 positions acting on the ring nut
located in the lower part of the shock absorbers with the specific spanner supplied.
Position 1: minimum preload: rider only
Position 2 medium preloading: rider only
Position 3 medium preloading: rider and passenger
Position 4: maximum preloading: rider, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
Spring preloading increases by turning the ring nut towards «A», but decreases if the
ring nut is turned towards «B».
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
WARNING
WE RECOMMEND WEARING GLOVES WHILE CARRYING OUT THIS OPERA-
TION IN ORDER TO AVOID INJURIES.
29
2 Use

PIAGGIO X7 EVO 300ie Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	278 cc
Fuel System	Electronic fuel injection
Front Brake	260 mm disc
Rear Brake	240 mm disc
Seat Height	790 mm
Fuel Tank Capacity	12 liters
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual hydraulic shock absorbers
