TECHNICAL DATA
Engine Single-cylinder, four-stroke
Bore x stroke 39 X 41.8 mm
Engine capacity 49.93 cm³
Compression ratio 11.5 :1
Ignition advance (before TDC) 8° at 1800 to 2000 rpm
24° at 5000 to 6000 rpm
Spark plug NGK CR8EB
Alternative spark plug DENSO U24ESR-NB
Depression carburettor KEIHIN CVK Ø 18 mm
valve clearance intake: 0.10 mm - exhaust: 0.10
mm
Max. speed According to current legislation
DATA
Overall length 1690 mm
Overall width 680 mm
Maximum height 1070 mm
Wheelbase 1250 mm
52
