Pioneer A-607R Service Manual

19
A-607R
Mark No. Description Part No.
Mark No. Description Part No.
AF ASSY
SEMICONDUCTORS
IC151 M5220P
IC451 NJM78M15FA
IC452 NJM79L15A
IC251 TA8409S
IC101 TC9163AN
IC301 UPC4570C
Q327, Q328, Q409, Q410 2SA1048
Q321, Q322 2SA970
Q311–Q314, Q329, Q330 2SA992
Q452 2SB1238X
Q309, Q310, Q315, Q316 2SC1845
Q333, Q334 2SC1845
Q319, Q320 2SC2240
Q317, Q318, Q331, Q332 2SC2458
Q407, Q408 2SC2458
Q301–Q304 2SC2878
Q451 2SC4793
Q102, Q104, Q153, Q403–Q406 2SK1132
Q414 2SK1132
Q401, Q402, Q413 DTA114ES
Q101, Q103, Q151 DTA124ES
Q152, Q251 DTC124ES
Q411, Q412 DTC143ES
Q323, Q324 IRF540
Q325, Q326 IRF9540
Mark No. Description Part No.
Mark No. Description Part No.
5. PCB PARTS LIST
NOTES:
•
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 10
1
→ 561 ........................................................ RD1/4PU
5 6 1
J
47k Ω→47 × 10
3
→ 473 ........................................................ RD1/4PU
4 7 3
J
0.5 Ω→R50 ..................................................................................... RN2H
R 5 0
K
1 Ω→1R0 ..................................................................................... RS1P
1 R 0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 10
1
→ 5621 ...................................................... RN1/4PC
5 6 2 1
F
kraMnoitpircseDdnalobmyS
.oNtraP
skrameR
epyTVMepyTWE/YMepyTRG/YMepyTDS
PSN
PSN
PSN
YSSAXELPMOCFA
YSSAFA
YSSALTNORF
YSSAEMULOV
YSSALORTNOC
YSSARTNORF
YSSAYRAMIRPCA
YSSAENOHPDAEH
YSSAWSREWOP
8647KWA
0027XWA
4507XWA
1717XWA
7107GWA
6417XWA
6507XWA
2507XWA
7507XWA
8647KWA
0027XWA
4507XWA
1717XWA
5107GWA
6417XWA
7917XWA
2507XWA
7507XWA
8647KWA
0027XWA
4507XWA
1717XWA
5107GWA
6417XWA
7917XWA
2507XWA
7507XWA
8647KWA
0027XWA
4507XWA
1717XWA
6107GWA
6417XWA
8917XWA
2507XWA
desutoN
LIST OF WHOLE PCB ASSEMBLIES
A
D451 D5SBA20
D151, D201, D202, D301–D306 HSS104-02
D309–D314 HSS104-02
D307, D308 HZS9A1L
D454 MTZJ33B
D453 MTZJ36B
D455 MTZJ4.7A
D457–D460 S5688G
COILS AND FILTERS
L201, L202, L401, L403 ATX1012
L405, L406 ATX1012
L151–L154 LAU221J
SWITCHES AND RELAYS
RY403 ASR1035
RY401, RY402 ASR7014
RY101, RY102 RSR1026
CAPACITORS
C461 (1µF/100V) ACH1237
C301, C302, C457, C458 ACH7027
(3.3µF/25V)
C451 (15000µF/50V) ACH7087
C452 (15000µF/50V) ACH7088
C101, C102, C105, C106 CCCSL101J50
C109, C110, C113, C114 CCCSL101J50
C153, C154 CCCSL221J50
C303, C304 CCCSL221K2H
C313–C316 CCCSL330K2H
C163, C164 CCCSL390J50
