Specifications
Note
• The specifications and design of this product are subject to change without notice.
•This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property
rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.
Do not connect the unit through a VCR. Video signals fed through VCRs may be affected by copyright protection
systems and the picture will be distorted on the television.
• Corporation and product names mentioned herein are trademarks or registered trademarks of the respective
corporations.
Model BDP-160
BDP-160-K
BDP-160-S
Type
Blu-ray 3D
TM
PLAYER
Rated voltage
AC 110 V to 240 V
Rated frequency 50 Hz/60 Hz
Power consumption 17 W
Power consumption (standby) 0.3 W
Power consumption (quick start) 7 W
Weight 2.0 kg
External dimensions (including projecting parts) 435 mm (W) x 58 mm (H) x 250 mm (D)
Tolerable operating temperature +5 °C to +35 °C
Tolerable operating humidity 5 % to 85 % (no condensation)
Output terminals
HDMI 1 set, 19-pin: 5 V, 250 mA
Audio outputs 2-channel (left/right) 1 set, RCA jacks
Audio output level 200 mVrms (1 kHz, –20 dB)
Frequency response 4 Hz to 88 kHz (192 kHz sampling)
Digital audio outputs Coaxial 1 set, RCA jacks
LAN 1 set, Ethernet jack (10BASE-T/100BASE-TX)
Wireless LAN (internal antenna) Integrated IEEE 802.11n (2.4 GHz band) wireless
networking access, compatible with 802.11b/g Wi-Fi
networks
USB 2 set, Type A
BDP-160_EN_ASEAN.book 57 ページ ２０１３年７月１７日 水曜日 午後４時１２分
