Pioneer DVR-7000 Service Manual

DVR-7000
STANDBY/ON
OPEN/CLOSE
Barrier Sheet
Unhook
Unhook
Unhook
MAIN UNIT
Stand up the
MAIN UNIT
to the hook.
Note:
MAIN ASSY operates
even if removing the DV
cable. Possible to diagnose
the TUNER ASSY,etc.(The signal of
the DV connection cannot be checked.)
MAIN UNIT
CN9001
(DV cable)
Unhook the bottom side
4 marking parts.
Remove the front panel.
Remove the
barrier sheet.
*
Disconnect the FFC
and PH cable.
Disconnect the connector
Tray Panel
Unhook
Clip ,etc
(about 1.0φ)
Rear side of the tray
1
CN2009
CN204
2
POWER SUPPLY
Assy
11
14
13
12
Remove the
front shield.
10
× 3
12
15
× 2
10
× 6
16
× 2
11
× 3
3
4
2
1
5
6
7
7
7
8
9
5
5
× 4
× 2
3.1.6 DISASSEMBLY
Remove the bonnet. (Screw ×10)
Open the tray.
Remove the
tray panel.
When opening the tray by manual operation
