Pioneer GM-222 User Manual

12
GM-222
GM-222/X1R/UC
AMP UNIT
Consists of
MOTHER PCB
ISOLATOR PCB
Unit Number : HWH0062
Unit Name : Amp Unit
MISCELLANEOUS
IC 451 IC UPC4570HA
IC 551 IC UPC4570C
IC 651 IC TA8194Z
IC 851 IC UPC4570C
IC 852 IC UPC4570C
IC 901 IC UPC494C
Q 551 Transistor 2SA1145
Q 552 Transistor 2SA1145
Q 553 Transistor 2SC2705
Q 554 Transistor 2SC2705
Q 555 Transistor 2SD2343
Q 556 Transistor 2SD2343
Q 561 Transistor 2SD2438
Q 562 Transistor 2SD2438
Q 563 Transistor 2SB1587
Q 564 Transistor 2SB1587
Q 651 Transistor 2SD1768S
Q 652 Transistor 2SD1768S
Q 653 Chip Transistor 2SA1162
Q 654 Transistor 2SC2458
Q 655 Transistor 2SC2458
Q 656 Transistor 2SC2458
Q 657 Transistor 2SA1048
Q 658 Transistor 2SC2458
Q 659 Transistor 2SA1048
Q 660 Transistor 2SB1243
Q 661 Transistor 2SC2712
Q 662 Transistor 2SC2712
Q 663 Chip Transistor 2SA1162
Q 901 Transistor 2SC2458
Q 902 Transistor 2SA1048
Q 903 Transistor 2SA1048
Q 904 Transistor 2SA1048
Q 905 FET IRFIZ44N
Q 906 FET IRFIZ44N
Q 907 Transistor 2SD1864
Q 908 Transistor 2SB1243
D 651 Diode 1SS133
D 652 Diode 1SS133
D 653 Diode 1SS133
D 654 Diode HZS7L(B2)
D 655 Diode 1SS133
D 656 Diode HZS7L(A2)
D 657 Diode 1SS133
D 658 Diode 1SS133
D 901 LED BR4361F
D 902 Diode ERA15-02VH
D 903 Diode ERA15-02VH
D 904 Diode HZS18L(3)
D 905 Diode 1SS133
D 906 Diode 1SS133
D 907 Diode ESAC25M-02C
D 908 Diode HZS16L(1)
D 909 Diode HZS16L(1)
D 910 Diode ESAC25M-02N
D 911 Diode 1SS133
L 851 Ferri-Inductor CTF1007
L 852 Ferri-Inductor CTF1007
L 901 Choke Coil 50H CTH1142
T 901 Transformer CTT1034
TH 901 Thermistor CCX1013
TH 902 Thermistor CCX1035
VR 453 Volume 10kΩ(A) CCS1241
EF 902 Capacitors CCG-081
EF 903 Capacitors CCG-081
RESISTORS
R 137 RS1/10S222J
R 138 RS1/10S222J
R 147 RS1/8S0R0J
R 148 RS1/8S0R0J
R 455 RS1/10S0R0J
R 456 RS1/10S0R0J
R 465 RS1/8S181J
R 466 RS1/10S181J
R 501 RD1/4PU221J
R 502 RD1/4PU221J
R 551 RS1/10S222J
R 552 RS1/10S222J
R 555 RS1/10S822J
R 556 RS1/10S822J
R 557 RS1/10S471J
R 558 RS1/10S471J
R 559 RS1/10S223J
R 560 RS1/10S223J
R 561 RS1/10S153J
R 562 RD1/4PU153J
R 563 RS1/10S153J
R 564 RD1/4PU153J
R 565 RD1/4PU561J
R 566 RD1/4PU561J
R 567 RD1/4PU561J
5. ELECTRICAL PARTS LIST
NOTE:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ --------------------------------------------- -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ --------------------------------------------- -------------------------
A

Pioneer GM-222 Specifications

General

Brand	Pioneer
Model	GM-222
Category	Amplifier
Language	English
