14
GM-222
C 652 470µF/16V CCH1183
C 653 CEAS470M16
C 654 CEAS220M50
C 655 CFTNA103J50
C 656 CKSQYB103K50
C 657 CKSQYB103K50
C 658 CKSQYB103K50
C 659 470µF/16V CCH1183
C 851 CCSQCH101J50
C 852 CCSQCH101J50
C 853 CEAL100M16
C 854 CEAL100M16
C 855 CKSQYB472K50
C 856 CKSQYB472K50
C 857 CCSQCH470J50
C 858 CCSQCH470J50
C 859 CCSQCH470J50
C 860 CCSQCH470J50
C 861 CEAS100M50
C 862 CEAS100M50
C 863 CKSQYB103K50
C 864 CKSQYB103K50
C 901 CEAS1R0M50
C 902 CEAS221M10
C 903 CEAS2R2M50
C 904 CEAS1R0M50
C 905 CQMA472J50
C 906 CQMA472J50
C 907 3300µF/16V CCH1130
C 908 3300µF/35V CCH1200
C 909 3300µF/35V CCH1200
C 910 CEAS101M35
C 911 CEAS101M35
C 912 CEAS100M50
C 913 CEAS100M50
C 914 CQMA102J50
C 915 CQMA102J50
C 916 CFTNA224J50
C 917 CQMA102J50
C 918 CKSYB103K50
=====Circuit Symbol and No.===Part Name Part No.
--- ------ --------------------------------------------- -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ --------------------------------------------- -------------------------
6. ADJUSTMENT
There is no information to be shown in this chapter.
GM-222/X1R/UC, GM-222/X1R/ES and GM-222/X1R/EW are constructed the same except for the following:
- Amp Unit
Part No.
GM-222/X1R/ES
Symbol and Description GM-222/X1R/UC GM-222/X1R/EW
S901 Switch Not used HSH-156
R869,872 RD1/4PU473J Not used
R926 Not used RD1/4PU105J
C851,852 CCSQCH101J50 CKSQYB471K50
C861,862 CEAS100M50 Not used
