Pioneer GM-5300T User Manual

11
Specifications
Power source ........................................................................................................ 14.4 V DC (10.8 V to 15.1 V allowable)
Grounding system .......................................................................................................................................... Negative type
Current consumption .................................................................................................... 30.0 A (at continuous power, 4 Ω)
Average current drawn* ...................................................................................................... 10.0 A (4 Ω for two channels)
19.0 A (4 Ω for one channel)
Fuse ........................................................................................................................................................................ 30 A × 2
Dimensions ........................................................................................................ 300 mm (W) × 60 mm (H) × 334 mm (D)
Weight .................................................................................................................... 3.9 kg (Leads for wiring not included)
Maximum power output .............................................................................................. 250 W × 2 (4 Ω) / 760 W × 1 (4 Ω)
Continuous power output .......................................................... 125 W × 2 (at 14.4 V, 4 Ω, 20 Hz to 20 kHz 0.2% THD)
380 W × 1 (at 14.4 V, 4 Ω, 20 Hz to 20 kHz 0.8% THD)
190 W × 2 (at 14.4 V, 2 Ω, 20 Hz to 20 kHz 0.8% THD)
Load impedance ........................................................................................................................ 4 Ω (2 Ω to 8 Ω allowable)
(Bridge connection: 4 Ω to 8 Ω allowable)
Frequency response .......................................................................................................... 10 Hz to 50 kHz (+0 dB, –1 dB)
Signal-to-noise ratio ...................................................................................................................... 95 dB (IEC-A network)
Distortion ........................................................................................................................................ 0.015 % (10 W, 1 kHz)
Separation ...................................................................................................................................................... 70 dB (1 kHz)
Low pass filter .............................................................................................................................. Cut off frequency: 80 Hz
Cut off slope: –12 dB/oct
Bass Boost .............................................................................................................................................. Frequency: 50 Hz
Level: 0 dB/6 dB/12 dB
Gain control .................................................................................................................................... RCA: 400 mV to 6.5 V
Speaker: 1.6 V to 26 V
Maximum input level / impedance ...................................................................................................... RCA: 6.5 V / 22 kΩ
Speaker: 26 V / 40 kΩ
Note:
• Specifications and the design are subject to possible modification without notice
due to improvements.
*Average current drawn
• The average current drawn is nearly the maximum current drawn by this unit
when an audio signal is input. Use this value when working out total current
drawn by multiple power amplifiers.

Pioneer GM-5300T Specifications

General

Impedance	8 Ω
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.015 %
Output power	760 W
Channels quantity	2 channels
Dimensions (WxDxH)	300 x 334 x 60 mm
Connectivity technology	Wired
Product color	Black

Weight and Dimensions

Weight	3900 g
