Main features
This unit features a Direct Energy HD Amplifier (Class
D amplifier) that was developed using the latest digital
amplifier technology. It is capable of simultaneous high-
power output and very high quality sound. This amplifier
provides you with the optimum playback of the latest multi-
channel digital content.
•
SC-LX801:
You can connect 9.1ch of speakers to this unit, with 9ch
at 200 W (6 ohms, 1 kHz, 0.9%THD) (North American
models) / 200 W (6 ohms, 1 kHz, 1%THD) (European
and Asian models) per channel plus pre out jack for
powered subwoofer.
•
SC-LX701:
You can connect 9.1ch of speakers to this unit, with 9ch
at 175 W (6 ohms, 1 kHz, 0.9%THD) (North American
models) / 185 W (6 ohms, 1 kHz, 1%THD) (European
and Asian models) per channel plus pre out jack for
powered subwoofer.
•
Supports playback in Dolby Atmos format and has
Dolby Surround listening mode
•
Supports playback in DTS:X format and has DTS
Neural:X listening mode
•
The HDMI jack supports 4K video input and output.
Jacks IN1 to 5 and OUT MAIN/SUB support HDCP2.2
•
HDMI CEC functionality: Control features such as
linking input switching with the input selector and
players conforming to the CEC standard, switching
audio output and volume using the remote controller of
a CEC-compliant TV, and automatically switching this
unit to standby when the TV is turned off
•
HDMI Standby Through: Video and audio signals from
AV components can be transmitted to the TV even if this
unit is in standby
•
ARC: Connection with an ARC-compatible TV is
complete with one HDMI cable
•
Easy Initial Setup using onscreen guidance and On-
Screen Display (OSD) showing operations on the TV
•
Internet radio and AirPlay via wired LAN or Wi-Fi
(wireless LAN) and network features such as Music
Server that enables PC music file playback, USB
playback, plus other playback features such as AM/FM
radio and BLUETOOTH
R
play
•
Playback formats supported by Music Server and USB
include WAV, FLAC and DSD high-res source
•
Multi-zone Connection which allows you to play in the
main room and listen in a separate room (ZONE 2/
ZONE 3)
•
You can connect a speaker B system
•
Equipped with RS-232C port, IR IN/OUT jack, and 12V
TRIGGER OUT jacks
•
Fitted with a Full Band Phase Control function. If the
speaker unit is divided into multiple parts, such as
tweeter and woofer sections, this corrects for group
delay (the difference between phase and timing)
between speakers. Further, by lining up the phases of
the connected speakers, the unit can achieve more
accurate reproduction across the full range (full band)
and across all channels.
•
By connecting an AV component that supports PQLS
(Precision Quartz Lock System) by HDMI, you can
reduce the affects of jitter that occurs during the transfer
of audio signals, so you get high quality playback of
audio from CDs, BDs, and DVDs.
•
This unit features PQFA (Precision Quartz for File-
based Audio) feature that enables high-quality playback
by greatly reducing jitter through the operation of the
high-precision Audio Clock device. It works when input
is switched to NET, USB, or BT AUDIO.
