Pioneer VSX-1021-K User Manual

En
82
13 Additional information
Auto Surround, ALC and Stream Direct with different input
signal formats
The following charts show what you will hear with different input signal formats, depending on the
Stream Direct mode (see Using Stream Direct on page 36 ) you have selected.
Stereo (2 channel) signal formats
Input signal format
Auto Surround / ALC /
DIRECT
PURE DIRECT
Surround Back speaker(s): Connected
Dolby Digital Surround
2 Pro Logic IIx MOVIE 2 Pro Logic IIx MOVIE
DTS Surround
Neo:6 CINEMA Neo:6 CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above PCM DIRECT
DVD-A sources As above As above
SACD sources As above Stereo playback
Surround Back speaker(s): Not connected
Dolby Digital Surround
2 Pro Logic II MOVIE 2 Pro Logic II MOVIE
DTS Surround
Neo:6 CINEMA Neo:6 CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above PCM DIRECT
DVD-A sources As above As above
SACD sources As above Stereo playback
Multichannel signal formats
Input signal format Auto Surround / ALC PURE DIRECT / DIRECT
Surround Back speaker(s): Connected
Dolby Digital EX (6.1 channel flagged)
Dolby TrueHD EX (6.1 channel flagged)
Dolby Digital EX
2 Pro Logic IIx MOVIE
<a>
Dolby Digital EX
2 Pro Logic IIx MOVIE
<a>
DTS-HD Master Audio ES (6.1 channel
flagged)
DTS-ES (Matrix) DTS-ES (Matrix)
DTS-ES (6.1 channel sources/6.1 channel
flagged)
DTS-ES (Matrix/Discrete) DTS-ES (Matrix/Discrete)
DTS sources (5.1 channel encoding) Straight decoding Straight decoding
DTS-HD sources As above As above
Other 5.1/6.1/7.1 channel sources As above As above
Surround Back speaker(s): Not connected
DVD-A sources/Multi-ch PCM Straight decoding Straight decoding
SACD sources (5.1 channel encoding) As above As above
Other 5.1/6.1/7.1 channel sources As above As above
a Unavailable with only one surround back speaker connected.

Pioneer VSX-1021-K Specifications

General

Impedance	8 Ω
Frequency range	20 - 20000 Hz
RMS rated power	- W
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	81 dB
Total Harmonic Distortion (THD)	0.05 %
Display	-
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS Neo:6, DTS-HD
HDMI in	5
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	Terminals
Headphone outputs	9
Headphone connectivity	3.5 mm
Connectivity technology	Wired
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	MPEG4
AM band range	530 - 1700 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	63
Supported video modes	1080p
Dimensions (WxDxH)	435 x 362.5 x 168 mm
HDMI ports quantity	6
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	550 W

Weight and Dimensions

Weight	10000 g
