74
SPECIFICATIONS
RANGER 500 Midsize RANGER CREW 500
Maximum Weight Capacity
(includes weight of operator,
passenger, cargo, accessories)
1000 lbs. (454 kg) 1250 lbs. (567 kg)
Dry Weight 1055 lbs. (478.5 kg) 1300 lbs. (589.7 kg)
Fuel Capacity 8.8 gal. (33.3 l) 8.8 gal. (33.3 l)
Engine Oil Capacity 2 qts. (1.9 l) 2 qts. (1.9 l)
Coolant Capacity 120 oz. (3.5 l) 170 oz. (5 l)
Overall Length 108 in. (274.3 cm) 140 in. (355.6 cm)
Overall Width 56.5 in. (143.5 cm) 58 in. (147.3 cm)
Overall Height 73 in. (185 cm) 73 in. (185 cm)
Wheelbase 72 in. (183 cm) 104 in. (264 cm)
Cargo Box Dimensions (Inside) 32x42x11.5 in. (81x107x29 cm) 32x42x11.5 in. (81x107x 9 cm)
Ground Clearance 10 in. (25.4 cm) 10 in. (25.4 cm)
Min. Turning Radius 150 in. (381 cm) 237 in. (602 cm)
Towing Capacity 1250 lbs. (567 kg) 1250 lbs. (567 kg)
Hitch Tongue Capacity 150 lbs. (68 kg) 150 lbs. (68 kg)
Max. Cargo Box Load 500 lbs. (227 kg) 500 lbs. (227 kg)
Engine 4 valve 4 stroke single cylinder with counter balance
Displacement 498 cc 498 cc
Bore x Stroke (mm) 92 x 75 92 x 75
Alternator Output 350 W 350 W
Compression Ratio 10.2:1 10.2:1
Starting System Electric Electric
Fuel System Electronic Fuel Injection Electronic Fuel Injection
Ignition Timing 30° @5000 RPM 30° @5000 RPM
Spark Plug NGK BKR6E NGK BKR6E
Lubrication System Dry Sump Dry Sump
Cooling Liquid Liquid
Front Suspension Dual A-arm w/9.6 in. (24.4 cm) of
travel
Dual A-arm w/9.6 in. (24.4 cm) of
travel
Rear Suspension Independent w/9 in. (23 cm) of
travel
Independent w/9 in. (23 cm) of
travel
