MAINTENANCE
Track Maintenance
WARNING
Moving parts can cut and crush body parts. When performing the
checks and adjustments recommended on the following pages,
stay clear of all moving parts. Never perform track measurement
or adjustments with the engine running.
Track Tensio n
Track adjustment is critical for proper handling. Always maintain
correct tension and alignment.
Track Tension Data Chart
Suspension Weight Measurement
Location
Slack
Measurement
M-10 10 lbs. (4.54 kg) 16″ ahead of rear
idler shaft
7/8″ -11/8″
(2.2 - 2.9 cm)
NOTE: Tension adjustments should be made only after the track is
warmed up and limber.
1. Turn the engine off.
2. Lift the rear of the machine and safely support it off the ground.
3. P lace the recommended weight or downward pressure on the t rack
at the specified distance (see chart) ahead of the center of the rear
idler wheel.
NOTE: Measure at the point where the weight is hanging.
