64
SPECIFICATIONS
General Specifications
P3000iE
POLARIS Power Generator
ALTERNATOR
AC Output Voltage 240V
DC Output Voltage 12V (5.0A)
Rated Output 2.8 kW (11.67A)
Maximum Output 3.0 kW (12.5A)
Frequency 50 HZ
Type Inverter
ENGINE
Model KG205
Type
4-stroke, OHV Air-cooled, Single
Cylinder
Displacement 196cc(12.0 cu in)
Compression Ratio 8.5:1
Engine Speed 3600 RPM with smart throttle off
Cooling System Forced Air
Ignition System Transistorized
Engine Oil POLARIS 5W-30 Generator Oil
Engine Oil Capacity 0.6 L (0.63 qt)
Intake Valve Clearance-Cold 0.10 mm (.004 in.)
Exhaust Valve Clearance-Cold 0.15 mm (.006 in.)
Spark Plug
Gap
WR7DC 0.6 - 0.7 mm (.024 - .028in.)
