4
1.2 I Technical specifi ca ons and parts list
1.2.1 Technical specifi ca ons
Energy source Booster pump coupled to the fi ltra on system
Minimum power required by
the booster pump
1 HP (if the distance from the equipment room is < 15 metres)
1.5 HP or more (if the distance from the equipment room is > 15 metres)
Working pressure 3.45 - 3.59 bars
Hose length 9.60 meters
Width of suc on inlet (cm) 7 cm
1.2.2 Cleaner parts list
: Filter's canisters access hatch lock
: Brushes
: Tyres
: Transport and remove-from-pool handle
: Front driving wheels
: Rear driving wheels
: Connector fastening point for the hose
: Thrust jet control (cleaner direc on)
: Thrust jet fl ow rate control
1.2.3 Hose parts list
1
Wall fi ng
Cleaner
: In-line fi lter
: Quick disconnect fi ng
1
: Pressure relief valve
: Connector for a achment to the cleaner
: Hose fl oats spaced 30 to 90 cm apart
: Swivels
