6
2.3 I Connec ng the hose to the wall fi ng
• Disconnect the universal wall fi ng (UWF®) connector ( ) from the quick disconnect plug ( ), see step .
• Screw the universal wall fi ng (UWF®) connector ( ) with the blue restrictor disc (the blue disc is already installed)
onto the wall fi ng inlet, see step .
• Insert the quick disconnect plug ( ) into the universal wall fi ng (UWF®) connector ( ) by rota ng in the clockwise
direc on, then pull outwards to lock in posi on, see step .
2.4 I Adjus ng the hose length
• With the end of the hose connected to the wall fi ng of the pool ( ), unwind the en re length of hose ( ) as far
as the sec on of the pool located the furthest away. Do not include steps or sea ng areas.
- The end of the hose must be situated ±15 cm from the furthest part of the pool ( ).
- If the hose is too short, add a feed hose sec on with fl oats, a swivel and two hose nuts, available from your retailer.
Adjust to the correct length.
• To avoid possible injury, use a suitable tool such as properly sized scissors and exercise care
when cu ng the hose.
• Cut the hose so that it is ±15 cm from the part of the pool located the furthest from the wall fi ng ( ).
Move the hose around the pool to determine the furthest part of the pool.
Cut 15 cm from the
furthest sec on of the
pool
