FACTORY DEFAULT PRELOAD SETTINGS
FACTORY DEFAULT PRELOAD SETTINGS
RZR XP EPS
WALKER
Front
1.49 inches (38 mm)
Rear
8.21 inches (209 mm)
DYNAMIX
Front
2.74 inches (6.96 cm)
Rear
9.47 inches (24.05 cm)
RZR XP 4 EPS
WALKER
Front
2.04 inches (51 mm)
Rear
5.13 inches (130 mm)
DYNAMIX
Front
2.75 inches (6.99 cm)
Rear
8.12 inches (20.62 cm)
RZR XP Trails and
Rocks Edition
Front
1.30 inches (3.3 cm)
Rear
8.17 inches (20.75 cm)
Follow these guidelines if you make adjustments to this suspension.
• Always return the suspension to the factory setting after the load is removed
from the vehicle. The increased suspension height will negatively impact
vehicle stability when operating without a load.
• Always apply the same adjustment setting to all four wheels.
Do not increase the spring preload by more than one inch (25.4 mm) over the
factory setting.
144
MAINTENANCE
