FEATURES AND CONTROLS
Seats
Before operating the vehicle, always push down on all seat backs to
ensure the latches are secure.
Seat Adjustments
On seats equipped with an adjustment lever under the front edge of the
seat, pull the lever to the left. Slide the seat forward or rearward to the
desired position. Release the lever. The seat will lock into the new
position.
For other seat styles, loosen (do not remove) the four screws located on
the seat bottom. Slide the seat forward or rearward to the desired
position. Tighten the screws to 4 ft. lbs. (5.4 Nm). Do not overtighten.
Seat Removal
1. Pull up on the seat latch lever
located under the rear edge of
the seat.
2. Tilt the seat forward.
3. Lift the seat upward to
remove it from the vehicle.
4. Reverse this procedure to
reinstall the seat. Make sure
the seat tabs at the front edge
of the seat slide under the
seat retainer bar.
5. Press down firmly at the rear
of the seat to engage the rear
latch.
