MAINTENANCE AND LUBRICATION
Lights
Taillight /Brakelight Lamp Replacement
If the taillight/brakelight does not work the lamp may need to be
replaced.
1. Remove the taillight lens cover
mounting screws. Remove the
lens cover and gasket and s et
aside for reassembly.
2. Remove the lamp (1) and
replace it with a new lamp.
3. Test the taillight/brakelight to
see that it’s working.
4. Reinstall the gasket and lens cover.
Indicator L amp Replacement
1. Remove the instrument panel, if necessary, to access the back of
the indicator panel.
2. Using a small, straight-blade screwdriver, turn the base of the bulb
1/4 turn counterclockwise.
3. Using a needle-nose plier or similar tool, pull t he lamp out of the
indicator panel housing.
4. Insert the new bulb and seat it by turning it 1/4 turn clockwise.
5. Reassemble the pod or front cover.
