40
THE PERFECT FIT
Handlebar Adjustment
Follow these steps to adjust handlebar angle at the handlebar block.
1. Remove the handlebar cover
to expose the handlebar and
the four adjuster block bolts.
2. Using a 7/16-inch wrench,
loosen the four nuts on the
bottom of the adjuster block
(turn the handlebar either left
or right for access to the rear
nuts). If necessary, pry the
blocks apart with a screw-
driver.
3. Adjust the handlebar to the
desired angle. Be sure the
handlebar, brake lever and
throttle lever operate
smoothly and do not hit the
gas tank, windshield or any
other part of the machine
when the handlebar is turned fully to the left or right.
4. Torque the front bolts first, then torque the rear bolts. Torque the
bolts to 11-13 ft. lbs. (15-18 Nm).
5. Reinstall the handlebar cover.
