Remove the front wheel assembly, wheels and frame from
the box.
Remove the axle caps and t the rear wheels by pressing
the release button and sliding onto the axle until the
clutch is engaged.
Slide the front wheel assembly into the frame and secure
using the two Hex bolts and washers provided polybag
using the supplied 4mm Hex Key.
Note: please save the hex hey for adjusting the handle
height
Note: On EBS models only, the wheels can be locked into
two positions on the axle; push onto the inner groove to
engage the clutches. The outer groove can be used when
drive is not required.
To open the frame, push the front wheel lever (highlighted
blue) towards the bag stay and rotate the front wheel
assembly until it locks into place. Secondly, press the main
lock button (highlighted blue) and lift the handle until the
rear and upper joints click into place.
Reverse the process to fold so that the handle hook locks
into the rear joint.
Attach the Wheels
Unfolding the Frame
Page 4
GETTING STARTED
