Front View
Control panel
Horizontal louvre
Vertical louvre
Body
Wheels
Handle
Handle
1.
2.
3.
4.
5.
6.
7.
Rear View
Body
Evaporator filter
Radiating filter
Heat exhaust hose connector
Heat exhaust hose connector
locking clip
Condenser filter
Wheels
Drainage plug / water outlet
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
Accessories
Remote control
Rectangle heat exhaust hose connector
Heat exhaust hose
Heat exhaust hose short connector
Sliding window sealing board assembly
Hinged window fabric sealing assembly
Sealing velcro
Water hose
Parts
05 | English
