2. INSTALLATION AND OPERATION
The series comes with two VAC systems: 208V and 400V. There are two different types of models: standard
and long-term models. Please refer to the following table.
We also offer optional parallel functionality for both models on request. UPSs with parallel functions are
called "Parallel models". We have details of the installation and operating procedure of the Parallel Model in
the following chapters.
2-1. Disassembly and Inspection
Open the package and check the contents of the package. The shipping package must contain:
● One UPS
● One user manual
● One CD monitoring software
● One RS-232 cable (option)
● One USB cable
● External battery bank connection cable (option)
● One parallel cable ( only available for parallel models)
● Single shared current cable (only available for parallel models)
NOTE:
Before installation, please check the unit. Make sure there is no physical damage to the unit. Do not
turn on the unit and notify the operator and dealer immediately of any damage or loss of parts and
accessories. Please keep the original packaging for future use. It is recommended to store each equipment
and battery set in its original packaging as it has been designed to provide maximum protection during
transportation and storage.
2-2. Wiring Terminal Display
Diagram 1: INSPIRE 83310-QS & INSPIRE 83320-QS Back Panel
