A–Specifications
Dimensions
59265-02 B A-5
Dimensions
Electrical
Power Cord Specifications
The switch comes with one or two power cords with NEMA 5-15 non-locking plugs
(SKU: CPK-9000-US). This power cord is approved for North America (USA,
Canada, Puerto Rico), Mexico, Central America, South America, Korea, Taiwan,
Philippines, and Thailand. A similar power cord with a locking plug is also
available (SKU: CPK-9000-USL). QLogic offers power cords for additional
regions/countries as listed in Table A-1.
Width...............................................
Height .............................................
Depth..............................................
17” (432mm), 19-inch rack mount
1.70” (43.2mm) (1U)
19.69” (500mm)
Weight
Model 5800V..............................
Model 5802V..............................
13.5lbs (6.1Kg)
16.3lbs. (7.4Kg)
Operating voltage ........................... 100 to 240VAC; 50 to 60Hz
Power source loading.....................
(maximum)
1.2A at 120VAC
0.6A at 240VAC
Heat Output (maximum) ................. 120W
Table A-1. Available Power Cords
Region/Country Specification
QLogic SKU
Number
Argentina IRAM 2073.1982 Plug CPK-9000-AR
Australia AS/NZS 3112 Plug CPK-9000-AUNZ
Bahrain BS1363/A Plug CPK-9000-UKHK
China (PRC) GB2099/GB1002-1 Plug CPK-9000-CN
Denmark Data DK-2-5A Plug CPK-9000-DK
Europe CEE 7/7 Plug CPK-9000-CEE
