QNAP TS-1635AX User Manual

QTS is installed.
Installing QTS Using the Cloud Key
Warning
Installing QTS deletes all data on the drives. Back up your data before proceeding.
1. Power on the NAS.
2. Connect the NAS to the internet.
3. Go to the QNAP Cloud Installation page using one of the following methods:
• On your computer, go to http://install.qnap.com/.
• Scan the QR code on the NAS using a mobile device.
The web page lists all the uninitialized QNAP NAS devices on the local network.
4. Find your NAS from the list and then click Initialize.
Note
If your NAS is not listed, follow the instructions on the web page to specify the Cloud Key on the
NAS.
The installation wizard opens in the default web browser.
5. Create an account or sign in to myQNAPcloud.
Note
You must return to this page to complete the installation after creating an account.
6. Specify the myQNAPcloud device name for the NAS.
Note
The myQNAPcloud device name is used when remotely accessing the NAS.
7. Optional: Select CloudLink.
Note
• CloudLink allows you to remotely access the NAS without having to configure port
forwarding on your router. You can remotely access the NAS by logging into QTS or by
using mobile apps.
• You can also enable CloudLink by installing the CloudLink app on the NAS.
8. Click Next.
9. Perform any of the following actions.
• To check for the latest available version, click Start.
The wizard downloads the latest available version, and then the NAS restarts after the download
is complete. If a newer version is not available, the wizard automatically displays the Smart
Installation Guide.
• To install the out-of-the-box version, click Skip.
TS-1635AX User Guide
Installation and Configuration 34

QNAP TS-1635AX Specifications

General

Internal memory	4 GB
Internal memory type	DDR4
Maximum RAM supported	16 GB
RAID levels	0, 1, 5, 6, 10, 60, JBOD
RAID support	Yes
Storage drive size	- \
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, exFAT, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Number of M.2 (M & B) slots	2
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	16
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Ethernet LAN data rates	10, 100, 1000, 10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
Fiber optic connector	SFP+
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Processor cores	4
Processor family	Marvell
Processor frequency	1.6 GHz
Processor architecture	ARM Cortex-A7
PCI Express slots version	3.0
Chassis type	Desktop
Cooling type	Active
Display type	LCD
Fan diameter	92 mm
Product color	Black
Fan diameter 2	60 mm
Number of fans	4 fan(s)
Cable lock slot type	Kensington
Number of built-in speakers	1
Type	NAS
Noise level	23 dB
Device class	Small & Medium Business
Backup features	Cloud, iSCSI LUN
Browser supported	Apple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms	256-bit AES
Fan voltage	12 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	250 W
Storage temperature (T-T)	5 - 95 °C
Operating temperature (T-T)	0 - 40 °C
Operating system version	4.3.4
Operating system installed	QNAP Turbo System
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	319.8 mm
Width	369.89 mm
Height	303.84 mm
