GL300 Manage Tool User Guide
TRACGL300MT001 - 27 -
3.2.9 Set the parameters of Function Key Setting
Step_1: Select “Function Key Setting”, after that the parameters of GTFKS show in Command
Operation Space.
Step_2: The command message which shall be sent to GL300 will be generated based on input
and displayed here. Please note this command message can also be sent to GL300
through SMS or GPRS.
Step_3: It is recommended to read the parameters from GL300 and edit based on them.
Step_4: Set the function key parameters. Please refer to “GL300 @Track Air Interface Protocol”
for the meaning of each parameter.
Step_5: Click the “Send” button; download the parameters of GTFKS to GL300.
Step_1
Step_4
Step_3
Step_5 Step_2
To Next Page
