GL300 User Manual
TRACGL300UM001 - 6 -
2.3. LEDs Description
There are three LEDs in GL300, the description as following.
2.4. External Power Interface
2.4.1. External DC Charger Interface
The Pin2 on Mini-USB connector are used for charging and named as VCHG pin, It can be
connected to a 5V DC power supply to power GL300 and charge the internal battery.
LED Event State
GSM LED
Searching network
Fast flash
Network has been registered Slow flash
Power off
Dark
SIM-PIN Locked
Solid
Receives a valid protocol command
Turn on for 3 seconds
<LED on> is 2
Dark
GPS LED GPS has fixed Solid
GPS is in fixing Fast flash
GPS is on and GPS data wrong Slow flash
GPS is off Dark
If <LED on> is 0, 150 seconds later after powers
on.
Dark
<LED on> is 2 Dark
Power LED Power on and normal Dark
Charger inserted and charging completed Solid
Charger inserted and charging Fast flash
Power key was pressed and prepare to power off Fast flash
Abnormal
Fast flash
Power low alert
Slow flash
Power off or turn off the power light by command
Dark
<LED on> is 2
Dark
