GL300W External Battery Kit User Manual
GL300WEBKUM001 -21-
6.2.2. GTTSW
The +RESP:GTTSW is used to indicate the logical status change of digital input 2.
Table 10: +RESP:GTTSW Message Format
Example:
+RESP:GTTSW,1A0100,135790246811220,,1,0,0,4.3,92,70.0,121.354335,31.222073,200902140
13254,0460,0000,18d8,6141,00,20100214093254,11F0$
Parameter Length(byte) Range/format Default
Protocol version 6 XX0000 – XXFFFF,
X∈{'A'-'Z','0'-'9'}
Unique ID 15 IMEI
Device name 10
Type 1 0|1 1
State 1 0|1
GPS accuracy 1 0 0
Speed <=5 0.0 – 999.9km/h
Azimuth <=3 0 – 359
Altitude <=8 ±XXXXX.X m
Last longitude <=11 ±XXX.XXXXXX
Last latitude <=10 ±XX.XXXXXX
GPS UTC time 14 YYYYMMDDHHMMSS
MCC 4 0XXX
MNC 4 0XXX
LAC 4 XXXX
Cell ID 4 XXXX
ODO mileage <=9 0.0 – 4294967.0Km 0
Send time 14 YYYYMMDDHHMMSS
Count number 4 0000 – FFFF
Tail character 1 $ $
 <Type>: reserved and its value is 1.
 <State>: defines the logical status of digit input 2.
 0: the logical status of digit input 2 is 0.
 1: the logical status of digit input 2 is 1.
 <
ODO mileage >: If the <ODO enable> in AT+GTCFG command was setted to 1, the bit will
be filled with ODO mileage, otherwise, the bit will be reservered.
6.2.3. GTOMS
If the PCU detects that the motion state changes according to motion sensor’s output or SW101
state changes, it will send +RESP:GTOMS message indicate this changes to the backend server
through GL300W.
