Quectel FC80A User Manual

Wi-Fi&Bluetooth Module Series
FC80A_Hardware_Design 27 / 43
4.4. Power Consumption
The following tables show the power consumption of the module in different modes.
4.4.1. Power Consumption in Low Power Modes*
This chapter information will be included in the future version of this document.
4.4.2. Power Consumption
Table 21: Power Consumption in OFF State and Idle
Table 22: Power Consumption in ANT_WIFI0/BT (SISO Mode, Unit: mA)
Description
Conditions
I
WLAN3V3
(Typ.)
I
VIO
(Typ.)
Unit
OFF State
AT+QWIFI=0
4
225
µA
Idle
AT+QWIFI=1
130
0.30
mA
Description
Conditions
VBAT (3.3 V)
VDDIO (1.8 V)
802.11b
TX (2.4 GHz) 1 Mbps
428
0.875
TX (2.4 GHz) 11 Mbps
416
0.875
802.11g
TX (2.4 GHz) 6 Mbps
400
0.850
TX (2.4 GHz) 54 Mbps
299
0.865
802.11n
TX (2.4 GHz) HT20 MCS0
409
0.864
TX (2.4 GHz) HT20 MCS7
279
0.870
TX (5 GHz) HT20 MCS0
376
0.840
TX (5 GHz) HT20 MCS7
293
0.847
TX (5 GHz) HT40 MCS0
383
0.841
TX (5 GHz) HT40 MCS7
295
0.848
802.11a
TX (5 GHz) 6 Mbps
392
0.44
