Quectel FC80A User Manual

Wi-Fi&Bluetooth Module Series
FC80A_Hardware_Design 41 / 43
6.3.3. Packaging Process
Figure 16: Packaging Process
Place the module into the carrier tape and use
the cover tape to cover them; then wind the
heat-sealed carrier tape to the plastic reel and
use the protective tape for protection. One
plastic reel can load 500 modules.
Place the packaged plastic reel, humidity
indicator card and desiccant bag into a
vacuum bag, then vacuumize it.
Place the vacuum-packed plastic reel into a
pizza box.
Put 4 pizza boxes into 1 carton and seal it. One
carton can pack 2000 modules.
