Quectel FC80A User Manual

Wi-Fi&Bluetooth Module Series
FC80A_Hardware_Design 30 / 43
4.5.1. Conducted RF Output Power
Table 25: Conducted RF Output Power at 2.4 GHz
Description
Rate
Typ.
Unit
802.11b
1 Mbps
18±2.5
dBm
802.11b
11 Mbps
18 ±2.5
dBm
802.11g
6 Mbps
18±2.5
dBm
802.11g
54 Mbps
16.5 ±2.5
dBm
802.11n (HT20)
MCS0
18 ±2.5
dBm
802.11n (HT20)
MCS7
15.5 ±2.5
dBm
Table 26: Conducted RF Output Power at 5 GHz
Description
Rate
Typ.
Unit
802.11a
6 Mbps
14±2.5
dBm
802.11a
54 Mbps
12±2.5
dBm
802.11n, HT20
MCS0
14±2.5
dBm
802.11n, HT20
MCS7
12±2.5
dBm
802.11n, HT40
MCS0
14±2.5
dBm
802.11n, HT40
MCS7
11±2.5
dBm
802.11ac, VHT20
MCS0
14±2.5
dBm
802.11ac, VHT20
MCS8
11±2.5
dBm
802.11ac, VHT40
MCS0
14±2.5
dBm
802.11ac, VHT40
MCS9
10±2.5
dBm
802.11ac, VHT80
MCS0
14±2.5
dBm
802.11ac, VHT80
MCS9
10±2.5
dBm
