LTE Module Series
EP06&EG06&EM06 GNSS AT Commands Manual
EP06&EG06&EM06_GNSS_AT_Commands_Manual 25 / 29
3 Examples
3.1. Turn on and off the GNSS
Default arguments are used in this example to turn on GNSS. After turning on GNSS, NMEA sentences
will be outputted from “usbnmea” port by default; and GNSS can be turned off via AT+QGPSEND.
AT+QGPS=1 //Turn on GNSS.
OK
//After turning on GNSS, NMEA sentences will be outputted from “usbnmea” port by default.
AT+QGPSLOC? //Obtain positioning information.
+QGPSLOC: 061951.0,3150.7223N,11711.9293E,0.7,62.2,2,0.0,0.0,0.0,110513,09
OK
AT+QGPSEND //Turn off GNSS.
OK
3.2. Application of GNSS <nmeasrc>
When GNSS is turned on and <nmeasrc> is set to 1, NMEA sentences can be acquired directly via
AT+QGPSGNMEA.
AT+QGPSCFG="nmeasrc",1 //Set <nmeasrc> to 1 to enable acquisition of NMEA
sentences via AT+QGPSGNMEA.
OK
AT+QGPSGNMEA="GGA" //Obtain GGA sentence.
+QGPSGNMEA: $GPGGA,103647.0,3150.721154,N,11711.925873,E,1,02,4.7,59.8,M,-2.0,M,,*77
OK
AT+QGPSCFG="nmeasrc",0 //Set <nmeasrc> to 0 to disable acquisition of NMEA
sentences via AT+QGPSGNMEA.
OK
AT+QGPSGNMEA="GGA" //Acquisition of NMEA sentences via AT+QGPSGNMEA was
