Quectel UG96 User Manual

HSPA/UMTS/GSM/GPRS Module Series
UG96&UG95&M95 R2.0 Compatible Design
UG96&UG95&M95 R2.0_Compatible_Design 12 / 42
3 Pin Description
This chapter describes the pin definition of UG96, UG95 and M95 R2.0, as well as the pin comparison
among them.
Table 3: I/O Parameters Definition
Table 4: Pin Comparison among UG96, UG95 and M95 R2.0
Symbol
Description
IO
Bidirectional
DI
Digital Input
DO
Digital Output
PI
Power Input
PO
Power Output
AI
Analog Input
AO
Analog Output
OD
Open Drain
UG96/UG95 M95 R2.0
Pin No.
Pin Name
IO
Description
Pin No.
Pin Name
IO
Description
1
RESERVED
/
/
/
/
/
/
2
RESERVED
/
/
/
/
/
/
3
GND
/
Ground
1
AGND
/
Ground
4
PCM_CLK
DO
PCM data bit
clock.
1.8V power
domain.
2
MIC2P
AI
Channel 2
Microphone
positive input.
