SBC NRG HIGH POWER - REV001A
MAINTENANCE - TECHNICAL DATA
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
MAINTENANCE
The battery charger does not need any maintenance. To ensure optimum performance from the equipment, once a
year check the cables and the electrical connections.
TECHNICAL DATA
(1)
Maximum rated value at normal use or in short circuit.
(2)
With battery charger not supplied by the AC network and with disabled monitor mode.
(3)
At 50% of the output current on resistive load.
(4)
Each output can supply the maximum value of nominal current. The sum of the currents supplied from each output can not exceed the maxi-
mum nominal value of the equipment.
(5)
With supply voltage equal to 230 Vac and output current equal to the maximum nominal value.
(6)
With supply voltage equal to 120 Vac and output current equal to the maximum nominal value.
(7)
Protection may be inefficient in some operative conditions.
(8)
Software/hardware double-check.
Cycoloy
®
is a registered trade mark of GE Plastics.
MODEL SBC 1200 NRG FR SBC 1450 NRG HR SBC 1950 NRG HR SBC 2450 NRG HR
OUTPUT CHARACTERISTICS
Maximum output current
(1)
100 A
(
)
60 A
(
)
80 A
(
)
100 A
(
)
Charge absorption voltage
14,1 Vdc EL open
14,4 Vdc EL
sealed
/ Gel / AGM
28,2 Vdc EL open
28,8 Vdc EL sealed /
Gel
/ AGM
Charge float voltage
13,4 Vdc EL open
13,8 Vdc EL sealed /
Gel
13,6 Vdc AGM
26,8 Vdc EL open
27,6 Vdc EL sealed
Gel
- 27,2 Vdc AGM
DC absorption from the batteries
(2)
< 3,5 mA < 5 mA
Residual ripple
(3)
< 100 mV RMS
Charging characteristics Automatic in three stages IUoU
Number of outputs
(4)
3
INPUT CHARACTERISTICS
Supply voltage
264÷83 Vac, with power
reduction under 108 Vac
264÷161 Vac,
with power reduction under 207 Vac
Frequency 45÷66 Hz
Maximum absorption
(230/240 Vac)
(5)
6,7 A 7,9 A 10,5 A 12,9 A
Maximum absorption
(120 Vac)
(6)
13,1 A -
Power factor (cos
ϕ
)
(5)
1,00
Efficiency
(5)
≥ 88% ≥ 92%
PROTECTION
Reverse polarity
(7)
Yes, through fuse
Overload Yes
Output short circuit Yes
Overvoltage in output
(8)
Yes
Overheating Yes
Battery overtemperature Yes, optional
AMBIENT CHARACTERISTICS
Operating temperature -15 ÷ +70 °C, with linear power reduction over +50 °C
Cooling Quick Smart Fan (Forced, with variable fans speed)
Noisiness (acoustic) < 51 dbA @ 1 m (42 dbA @ 1 m in silent mode)
Humidity Max. 95% RV without condensation
CASE
Material Aluminium - Cycoloy
®
Dimensions (WxHxD) 243 x 557 x 116 mm
Weight 6,9 kg
GENERAL
CAN BUS interface Yes
Charge compensation Yes, optional (max 128 battery temperature sensors)
Safety standard EN 60335-2-29
EMC Standard EN 55022/B - FCC TITLE 47 PART 15 SUBPART B CLASS B
