Page #4 background imageLoading...
Page #4 background image
QUIETCOOLSYSTEMS.COM
4
2. INSTALLATION
2-1 Installing the Hub
IMPORTANT: If you are installing the Hub onto an existing QuietCool fan, be sure
to shut off the power before attempting installation. If you are installing the Hub
onto a new fan, perform all installation steps before plugging in the fan.
Install the Hub directly to the motorhead:
1. Remove the handy box cover on your QuietCool fan. Remove the wire nuts from the power
cord and motor wires inside the handy box. Remove the ground screw.
2. Remove the power cord bushing and power cord. Keep both the bushing and power cord as
you will be using it for the installation of the hub.
3. Remove the four screws that are used to mount the handy box to the QuietCool motorhead.
Retain the four screws as you will be using them to attach the Hub to the QuietCool
motorhead.
4. Using your philips screwdriver, open up the Hub and install the powercord bushing through
the hole at the back of the hub.
5. Run the motor wire leads through the large knockout in the bottom of the hub.
6. Using the four screws from the handybox, mount the Hub to your QuietCool motorhead.
2-2 Wiring the Hub
NOTE: Wiring Diagrams are for examples only and wiring should be done
by an experienced electrician. 12 or 14-gauge romex is common. Check your
local building code before choosing the wire type.
NOTE: Ensure the power is disconnected before performing any wiring
connections.
NOTE: The wiring diagrams and instructions are shown using the power cord
included with your QuietCool. The installation can also be performed with
2-wire romex and hard wired.
NOTE: If you are retrofitting the RF Control, you will have to un-wire the existing
wall swtich. You will reuse the power that was run to the switch to go directly into
the RF Control Hub.
TOOLS YOU WILL NEED
- Phillips screwdriver - Power-drill - Philips bit
