INDOOR MODEL
2. Mount new timer
OUTDOOR MODEL
For installation in drywall, use drywall anchors (included in package).
24VAC
ACCESSORY
SENS
123 4567 8C M
RESET
CONNECT
120 VAC
24VAC
ACCESSORY
SENS
123 4567 8C M
RESET
1/8 IN.
1/8 IN.
If hard wiring for AC power,
remove knockout for conduit.
