17.4ImportandExport

Waypoints,RoutesandTrackscanbeimportedand

exportedusingamemorycard.

Fordetailsonimportingandexportingwaypoints,

routesandtracksreferto:8.5Savinguserdataand

usersettings.

17.5Waypoints,routesandtracks

storagecapacity

Thedisplaycanstorethefollowingquantitiesof

waypoints,routesandtracks

Way-

points

•3000waypoints

•100waypointgroups,eachgroupcancontain

upto3000waypoints

Routes•150routes,eachroutecancontainupto200

waypoints

Tracks•15tracks,eachtrackcancontainupto10,000

points

Waypoints,RoutesandTracks

227
