20.7Settingboatdetails

YoucanchangevesselsettingsfromtheData

applicationmenu.

FromtheDataapplication:

1.SelectMenu.

2.SelectBoatDetails.

3.SelectNum.ofEngines,Num.ofFuelTanks,

orNum.ofBatteries.

4.Selecteither1,2,3,4or5.

Ifthenumberofengineshasbeenchangedthen

theEnginedatapagewillberesettodisplaythe

correctnumberofengines.

20.8SettingmaximumengineRPM

YoucansetthemaximumRPMrangetodisplayon

theRPMdataitem.

Fromthedataapplication:

1.SelectMenu.

2.SelectMaxRPMRange.

AlistofavailableRPMsettingsisdisplayed.

3.SelecttherequiredRPMrange.

AtickwillbeplacednexttotheselectedRPM

rangeinthemenuandtheRPMrangeonthe

enginedatapagewillbechangedtoyournew

setting.

Examples

Auto*

10,000RPM

Note:*ThemaximumRPMwheninautomodeis

setbytheengine.

306aSeries/cSeries/eSeries
