ItemDescription
4.
Multifunctiondisplay
5.
Vessel’sexistingGPSantenna
Extendedsystemexample
NMEA0183 - 4800
45
2
3
1
Sta tus
PWR/Da ta
ST
ng
VHF ANT
AIS650 Clas s B Tra nsce iver
GPS ANT
USB
00
4
46
47
12 V / 24 V
SeaTalkng
D12 0 95-1
ItemDescription
1.VHFAntenna
2.VHFRadio
3.
VHFSplitter(Notsupplied)
4.
AIS650transceiverunit
ItemDescription
5.
GPSantenna(suppliedwithAIS650
transceiver)
6.
Multifunctiondisplay
7.
Vessel’sexistingGPSantenna
Note:AMultifunctiondisplayconnectedtotheAIStransceiver
cannotusetheGPSwhichisconnectedtotheGPSconnection
onAISunit.
38AIS350/AIS650Installationinstructions
