•Ifyouneedtoe
xtendthelengthofthepowercable,ensureyouusesuitablyratedcableandthat
sufficientpower(12Vdc)isavailableattheSeaTalkng®backbone’spowerconnection.
Important:
Beawarethatthesuitablefuseratingforthethermalbreak
erorfuseisdependentonthenumber
ofdevicesyouareconnecting.
Moreinformation
Itisrecommendedthatbestpracticeisobservedinallvesselelectricalinstallations,asdetailed
inthefollowingstandards:
•BMEACodeofPracticeforElectricalandElectronicInstallationsinBoats
•NMEA0400InstallationS
tandard
•ABYCE-11AC&DCElectricalSystemsonBoats
•ABYCA-31BatterychargersandInverters
•ABYCTE-4LightningProtection
Sharingabreaker
Wheremorethan1pieceofequipmentsharesabreakeryoumustprovideprotectionforthe
individualcircuits.E.g.byconnectinganin-linefuseforeachpowercircuit.
1
P ositive(+)bar
2
Negative(-)bar
3Circuitbreak er
4Fuse
Wherepossible ,connectindividualitemsofequipmenttoindividualcircuitbreakers.Wherethisis
notpossible,useindividualin-linefusestoprovidethenecessaryprotection.
Connections37
