34 DSM300 Operation with PLUS Series Displays
Language
Select the language in which you wish information to be displayed. The selected
language will be used for screen text, labels, menus, and options, but will not
affect the letters displayed by the context-sensitive cursor. The language setting
also affects the display format for lat/long position information.
Simulator
The simulator enables you to operate your display without data from the
transducer and/or external data sources. The system set up simulator options
have the following functions:
• Data provides simulated numerical data, and a waypoint display.
• Radar provides simulated radar picture, with example targets. The picture
does not change if you change the range, although the range rings are
adjusted (see radar documentation).
• Both provides simulated data and radar picture.
When the simulator is switched on, a SIMULATOR data box is displayed during
operation, showing the simulation selected.
Sonar simulator mode is set in the Sonar setup menu, described in Section 3.4.
3.4 Sonar Set Up Parameters
The SONAR SET UP option enables you to set up the sounder according to your
system configuration and your personal preferences.
The following table lists the Sonar Set Up parameters and their options, shows the
factory default setting, and provides a space for you to make a note of your new
setting. Each parameter is described in the following subsections.
Table 3-3: Sonar Mode Set Up Parameters
Parameter Options
Factory
Default New Setting
TARGET DEPTH ID OFF
ON
OFF
COLOR BAR OFF
ON
ON
DEPTH DIGIT SIZE LARGE
SMALL
LARGE
SONAR
SET UP¬
