72 DSM300 Operation with PLUS Series Displays
Note:
When in chart mode, if you place a waypoint at the cursor position, it is not shown
on the display in Sonar mode.
If you place a waypoint at the boat position in Sonar mode it is shown in the chart
window.
Placing a Waypoint
➤ To access the place waypoint soft keys, press MARKS:
➤ To place a waypoint at the cursor position or at the vessel position:
1. Press either the PLACE WPT AT CURSOR or the PLACE WPT AT VESSEL soft
key. The waypoint is added to the waypoint list and tagged using the next
available number.
The waypoint soft keys are displayed until you move the cursor away from the
waypoint or press CLEAR.
You can use the EDIT WAYPOINT soft key to name the waypoint as described
in Editing Waypoints below.
2. Press CLEAR or ENTER to remove the place waypoint soft keys.
D5572-1
PLACE WPT
AT CURSOR
PLACE WPT
AT VESSEL
WAYPOINT
LIST
LOAD/SAVE
USER CARD
MARKS
PLACE WPT
AT CURSOR
PLACE WPT
AT VESSEL
D4163-1
GOTO
WAYPOINT
EDIT
WAYPOINT
ERASE
WAYPOINT
MOVE
WAYPOINT
