Chapter 3: System Setup 35
Target Depth ID
You can select whether the depth is shown for sonar echoes displayed on the
screen. When Target Depth ID is set to ON, the depth is displayed just above each
fish echo. When set to OFF, the depth of each echo is not displayed.
Color Bar
The color bar indicates the range of echoes displayed in each color (shade of gray
for monochrome displays). When set to ON the color bar is displayed on the right
hand side of the display.
Depth Digit Size
The depth under the boat is displayed in the bottom left hand corner of the display.
You can select small or large digits for the depth display.
Sonar HSB Mode
Note:
This parameter only pertains when the display to which you are outputting DSM300
image data is a PLUS Series fishfinder. If your display is a PLUS Series radar or chartplotter
display, the REPEATER setting is automatically selected and cannot be changed.
The Sonar HSB Mode setting designates whether the display showing sounder
data is the MASTER unit from which depth data is to be sourced or a REPEATER of
sonar data received from a master unit. Only one unit should be designated the
master at a time.
SONAR HSB MODE REPEATER
MASTER
MASTER
DEPTH OFFSET Value 0.0
SPEED CALIBRATE 0% to 200% 100%
TEMP CALIBRATE –9.0 °F to +9.0 °F0°F
SONAR HISTORY LARGE or SMALL LARGE
SONAR INT REJ AUTO, LOW or HIGH AUTO
SONAR SIMULATOR OFF
ON
OFF
Table 3-3: Sonar Mode Set Up Parameters
Parameter Options
Factory
Default New Setting
