Raymarine E70141 User Manual

10.6Trueandapparentwindpages
ApparentandTruewindpages
D12 5 19-1
3
4
2
1
1.Winddirectionwithrespecttovesselheading.
2.Vesselheading.
3.Windangle,eitherA(apparent)orT(True).
4.Windspeed,eitherapparentortrue,asindicated
initem3.
Lockedapparentwindpage
D12 5 20-1
S TEE R
4
5
2 3
1
1.Directiontosteerindicator,toachievelocked
windangle.
2.Flashingsegmentindicatesthedifference
betweentheapparentwindangleandthelocked
windangle.
3.Lockedwindangle.
4.Relativedirectionofthelockedwindangle:
•P=Port.
•S=Starboard.
5.Apparentwindspeed.
Note:IfLOCKisdisplayedon-screenthenthe
windangleiscontrolledbythecoursecomputer
andcannotbechangedmanually.
10.7Usingthewindpages
Tocyclethroughthewindpagesfollowthesteps
below:
10
15
20
25
30
35
40
45
50
55
60
5
3
D12 5 13-1
CAL
STEER
+
-
2
3
1 4
SeaTalk
1ApparentWind.
2TrueWind.
3
HighSpeedWindAlarm
4LockedApparentWind
Note:TheHighwindspeedalarmpageisonly
availableonmasterunits(SeetheDatamaster
sectionfordetails),itisatemporarypagewhich
willtimeoutafter5secondstotheprevious
permanentpage.
1.UsetheUpandDownbuttonstocyclethrough
theavailablepages.
2.PressingtheActionbuttonfromtheApparent
Windpagewillapplythecurrentwindbearing
asthelockedheadinganddisplaytheLocked
ApparentWindAnglepage.
3.PressingtheActionbuttonfromtheLocked
ApparentWindpagewillreturntotheApparent
Windpage.
4.PressingandholdingtheUpbuttonfromthe
HighWindSpeedAlarmpagewillswitchtheHigh
WindSpeedAlarmOn(default)andOff.
Note:Fordetailsonenabling,disablingand
adjustingalarmthresholdspleaserefertoChapter
11Alarms.
i40Wind61
