2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
support if required.
This and other Raymarine product documents
are available to download in PDF
format.
Applicable products
This document is applicable to the following products:
PartnumberNameDescription
A80288
GA150GNSS(GPS
/GLONASS)
antenna
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
GA150Installationinstructions
InstallationofaGA150antennaand
connectiontoacompatibleMFD.
87230/
88038
GA150Surfacemounttemplate
Mountingdiagramforsurfacemountinga
GA150.
87224
LightHouse
™
Operationinstructions
Describestheoperationandcongurationof
allLightHouse
™
MFDs..
81360
2.2GA150Partssupplied
ThepartssuppliedwithyourGA150GNSS(GPS/
GLONASS)antennaareshownbelow.
D13075-1
1
2
3
4 7
5
6
1.GA150antenna(Theantennaissuppliedwitha
tted10m(33ft.)cableforconnectiontoyour
MFD.)
2.GA150mountinggasket
3.Polemountadaptor
4.2xThumbsnuts
5.2xStuds
6.2xscrews
7.Documentpack
