3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanning
anyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.The
diagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
3.2GA150MFDcompatibility
TheGA150antennaiscompatiblewiththefollowing
Raymarine
®
LightHouse
™
MFDs:
•aSeriesa95/a97/a98/a125/a127/a128.
•eSSerieseS97/eS98/eS127/eS128
Multifunctiondisplaysoftwarerequirements
TheoperationofthisproductrequiresaRaymarine
®
MFDrunningLightHouse
™
software.
Raymarine
®
MFDvariant
LightHouse
™
software
requirement
aSeriesa95/a97/a98/
a125/a127/a128
Version11orlater
eSSerieseS97/eS98/
eS127/eS128
Version14orlater
