Raymarine HYPERVISION HV-100 User Manual

2.5P
artssupplied
Thefollowingpartsaresuppliedwithyourproduct:
Unpackyourproductcarefullytopreventdamageorlossofparts.Checktheboxcontentsagainst
thelistbelow.Retainthepackaginganddocumentationforfuturereference.
1T ransombracket
2
3xbrack etfixingscrews(4.2x19mmA4stainlesssteel)
3
M5 x10hexbolt(A4stainlesssteel)
4
M5washer(A4stainlesssteel)
5Hangerbrack et
6
Escutcheonplate(usedwhenroutingcablethroughtransomorabulkhead)
7
2xadjustmentslotwashers
8
T ransducerwith6m(19.69ft)fittedcable
9
4xescutcheonplatefixings(#8x13SUS316)
103xcableclips
11
3xcableclipfixings(#8x13SUS316)
12
Documentationpack
13
M6 x70hexbolt(A4stainlesssteel)
14
M6washer(A4stainlesssteel)
15
M6lockingnut
14

Raymarine HYPERVISION HV-100 Specifications

General

Brand	Raymarine
Model	HYPERVISION HV-100
Category	Transducer
Language	English
