3.
1Toolsrequired
Thefollowingtoolsarerequiredtoinstallyourtransducer:
1.P owerdrill
2.4mmhexwrench(Allenkey)
3.5mmhexwrench(Allenkey)
4.Pozi-drivescrewdriver
5.Drillbit(suitableforpilotholes)
6.Marinegradesealant
7.24mm(15/16in)orsuitablesizeholecutter(onlyrequiredwhenroutingthecablethrougha
bulkheadortransom)
8.Masking/adhesivetape
Warning:Marine-gradesealant
Onlyusemarine-gradeneutralcurepolyurethanesealants.DoNOTusesealants
containingacetateorsilicone,whichcancausedamagetoplasticparts.
